Cardboard packer with strong performances
- Robust & precise blank picking; frequency of magazine loading reduced; sensitivity to cardboard quality and thickness reduced
- All change settings have been removed, speeding up production and reduced changeover time
- Increased access and visibility for operators, facilitating cleaning, maintenance and setting changes
Características
Servo technology
Robust design of critical functions
- Belt brake: simplified mechanical settings; reduced slipping
- Box pusher: high package stability and repeatability of delivery position
- Blank extraction: robust & precise blank picking, reduced frequency of magazine loading and reduced sensitivity to cardboard quality and thickness
- Discharge unit: extended discharge unit for flawless control of downstream conveyor
Tray forming area
Reduced changeover time
- Number of total settings reduced by > 50%
- Magazine, tray forming and wraparound settings reduced by > 60%
- Synchronised and common settings: all blank width settings are in the tray forming and magazine area, including flap folders and feed chain
Transfer belt & stop plate
Speed up production
All change settings have been removed in this area, speeding up production.
New magazine handling
Improved cardboard blanks magazine
- Reduces change over time
- Easily accessible from ground level
- Synchronised magazine and feed chain settings
- Higher capacity blanks magazine
Optimised operator access
Optimised operator access
- Increased access and visibility for operators, facilitating cleaning, maintenance, setting changes and more
- Hotmelt unit moved to floor level on standard machine, facilitating glue filling
Opciones
Hotmelt on demand
Hotmelt on demand
Delivers hotmelt as required from a large bin connected to the CBP hotmelt unit = more energy efficient, reduced hotmelt waste and reduced operator intervention
Discharge options
Greater layout flexibility
Tetra Pak® Cardboard Packer 34 can be delivered with various discharge options to fit your layouts
1. Roller conveyor is a passive straight conveyor, used for hand-packing
2. Discharge unit
Driven unit conveyor – left or right
3. Discharge unit
Driven unit conveyor through-solution: two cardboard packers can be connected to the same discharge conveyor. Highly cost-efficient when using one palletiser or tray shrink wrapper for two lines.
