Vorteile
Mit dem Modul Tetra Pak® Casomatic System SC7 produzieren Sie Käse und Molke in höherer Qualität und effizienter als je zuvor. Das Tetra Pak Casomatic System SC7 ist ein vollautomatisches und kontinuierliches System zur Entmolkung, Vorpressung, präzisen Käseblockformung und Abfüllung von Käse in einem Vorgang.
Es eignet sich für die Herstellung von Hart- und Schnittkäsesorten. Durch den zusätzlichen Einbau eines Entmolkungssiebes können auch geschüttete Käsesorten produziert werden.
Die hohe Kapazität pro Säule wird durch den Einsatz eines flexiblen Molkeabzugssystems erreicht. Bei der Herstellung einer immer gleichen Käsegröße ist das Tetra Pak Casomatic System SC7 das System der Wahl.
Das Tetra Pak Casomatic System SC7 bietet Ihnen folgende Vorteile:
- Effiziente Lösung
- Lange Produktionsläufe
- Zuverlässige Leistung
- Ausgezeichnete Qualität der Molke
- Präziser Wassergehalt
- Hervorragende Gewichtsgenauigkeit
- Gute Käsequalität
- Bessere Umweltleistung
Efficient, effective medium to high volume cheese production
- High-quality cheese and whey production thanks to the gentle treatment of cheese and his self-cleaning functionality
- Maximum yield, with tightly controlled process that eliminates weight and moisture variations
- Certified machinery with hygienic operation enhances food safety, and enables shorter cleaning cycles
Merkmale
Dimple jacket cooling
Reduces variations in moisture content
A dimple jacket is wrapped around the conical part of the buffer tank, cooling the curd/whey mixture during filling, residence and emptying. This slows down the acidification process, thereby limiting the degree of variation in moisture content of the final cheeses from beginning to end of batch.
Buffer tank design
Ensures a consistent whey /curd ratio
Based on many years of accumulated expertise and experience, we’ve developed a buffer tank with the optimal inner dimensions and agitator to maintain an almost constant ratio of curd and whey and a constant curd particle distribution. This results in a curd mixture of uniform consistency to be fed into the casomatic system.
Drainage system
Controls the volume of whey that is drained off
The drainage system is divided into three perforated sections, gently draining off whey at each step until the desired amount (according to the pre-set recipe) has been removed - in order to create a stable, compact curd block. A regulating membrane valve is used to control the flow of whey and ensure the optimal amount is removed. The gentleness of the process keeps the product intact and minimizes losses.
Whey circulation system
Keeps the machine clean during production
A whey circulation system keeps the curd fines in the draining section in motion and prevents sedimentation. Flow dividers minimize curd build-up on the flanges of the inserts, limiting the growth of microorganisms during production and enabling a shorter CIP cycle.
Curd block forming
Gives cheese blocks with a high-quality appearance
Once cut from the curd bed, the curd block is gently transferred to the front of the machine. The mould is presented underneath the sluice plates, which open swiftly minimizing friction when transferring the block to the mould.
Automation system
Monitors production and compensates for disturbances
Our advanced control software is programmed to continuously monitor production and minimize the effects of any unexpected disturbances on the line. Since the composition of cheese changes rapidly, it is important to compensate for any deviation in production by e.g. adjusting cutting height or cooling the buffer tank. The control system does this automatically, without the need for any operator intervention.
Conveyor
Gentle handling
Presenting moulds to the columns, collecting curd blocks and transporting the filled moulds to the pressing system, the mould conveyor handles your product gently every step of the way. It includes a lifting buffering system to ensure the curd blocks land softly in the mould on the conveyor, and smooth transport from the columns to the presses.
Dosing chamber design
For more hygienic production
The enclosed dosing chamber is designed to allow whey to flow down from top to bottom, preventing any curd build-up. This continuous flow of whey is combined with regular flushing to minimize bacterial growth and enable longer production runs.
Ohne Neuanschaffung mehr aus Ihren Anlagen holen
Ob Koagulationssensor für den exakten Schnittzeitpunkt, neue Antriebe oder automatische Labdosierungssysteme – Tetra Pak Upgrades optimieren Ihre Käseproduktion ganz ohne Investition in eine neue Anlage. Das bedeutet für Ihre Produktion: Längere Lebensdauer, höhere Ausbeute (dadurch höhere Rentabilität), bessere Produktqualität und niedrigere Betriebskosten.
Verschaffen Sie sich einen Überblick über unsere Upgrades in unserem Katalog und erfahren Sie, mit welchem Upgrade Sie Ihre Produktion verbessern.
